DIGITAL ELECTRONICS LABORATORY (Z0609)

Digital Electronic laboratory is designed to conduct Digital Electronic practical for students in all disciplines.

In this laboratory, students have the chance to work with hardware such as discrete digital devices and FPGAs. Laboratory is equipped with different advanced test equipment such as Digital Storage Oscilloscopes, Digital Signal generators, Digital multimeters and Trainer panels. It Consists of ten (10) test benches with a capacity of 30 students to conduct experiments at a time.

RESOURCES
NAME OF THE ITEM SPECIFICATION & FUNCTION
Digital Oscilloscopes Tektronix - Dual Channels/200MHz, 150 MHz, 100 MHz, 60 MHz, 40 MHz, 25 MHz bandwidth models/Up to 1 GS/s sample rate on all channels
Arbitrary/Function Generators

Can be used to generates all kinds of waveforms needed in a lab.

Tektronix - Dual Channels/ With 25 MHz or 60MHz bandwidth, 1 mVpp to 10 Vpp output amplitude across full bandwidth, 14-bit vertical resolution and 1Hz frequency resolution

Dual Power Supply It has two independent and isolated outputs each with a 0 to 35V, 0 to 4A capability.
Dual Display Multimeters Can view two parameters simultaneously. 11 basic measurements and up to six built-in math functions
Logic Trainer Panels (MCM8/EV)

Can be used for investigating several typical applications of digital circuits. It contains all the pre-assembled electronic components needed to construct the experiment circuits.

Multiplexer, De-multiplexer, Asynchronous and synchronous counters, Traffic light simulator, Digital transmission/reception systems, Encoder/decoder Manchester code, Encoder/decoder double phase code, Encoder/decoder 1-bit differential code

Logic Trainer Panels (MCM9/EV) Experiment Board for the study of digital circuits, starting from basic logic and progressing through to sequential and combinational logic networks.


















IN-CHARGE OF LABORATORY

Mrs. SM KANNANGARA

Mrs. SM Kannangara
Lecturer-in-charge

Mr. DMBP Dhanapala

Mr. DMBP Dhanapala
Technical Officer

Eng. (Mrs.) D Y Tharangika Bambaravanage

Mrs. WMH Silva
Lab Attendant
